5W 3KVac Isolation Regulated Output
5W 3KVac Isolation Regulated Output
For detailed information on this product, please refer to the manufacturer's Full Specification below
5W 3KVac Isolation Regulated Output
| Model | Output Voltage | Output Current | Efficiency | Ripple and Noise |
|---|---|---|---|---|
| GX005-S03 | 3.3 | 1200 | 72 | 100 |
| GX005-S05 | 5 | 1000 | 75 | 100 |
| GX005-S06 | 6 | 850 | 75 | 100 |
| GX005-S07 | 7 | 725 | 75 | 100 |
| GX005-S08 | 8 | 625 | 75 | 100 |
| GX005-S09 | 9 | 600 | 78 | 100 |
| GX005-S10 | 10 | 600 | 78 | 100 |
| GX005-S12 | 12 | 500 | 80 | 100 |
| GX005-S13 | 13 | 460 | 80 | 150 |
| GX005-S14 | 14 | 425 | 80 | 150 |
| GX005-S15 | 15 | 400 | 80 | 150 |
| GX005-S16 | 16 | 375 | 80 | 150 |
| GX005-S18 | 18 | 333 | 81 | 240 |
| GX005-S24 | 24 | 250 | 82 | 240 |
| GX005-S27 | 27 | 220 | 82 | 240 |
| GX005-S36 | 36 | 167 | 82 | 240 |
| GX005-S48 | 48 | 125 | 82 | 240 |
Features Input voltage range: 70-264VAC Operating temperature: -40℃ to +70℃ Suitable for BF application Protection: OVP, OLP, OTP, SCP 2MOPP Meets DoE Level VII Extremely low leakage current <0.1mA Operating altitude: up to 5000M Designed to meet ISN & 60335 High surge immunity Built-in EMI filter LED indicator 3-year warranty IP22 rated
