FEATURES： ⚫ Universal Input 85~305VAC ⚫ High Efficiency Up to 81% ⚫ Protection: Short Circuit / Over Load ⚫ Ultra Small Size ⚫ 2 Years Warranty ⚫ RoHS Compliant
26~48W 3KVac Isolation Regulated Output AC to DC Power Conversion
For detailed information on this product, please refer to the manufacturer's Full Specification below
26~48W 3KVac Isolation Regulated Output AC to DC Power Conversion
| Model | Output Voltage | Output Current | Efficiency | Ripple and Noise |
|---|---|---|---|---|
| GA030-S03 | 3.3 | 8000 | 72 | 150 |
| GA030-S05 | 5 | 8000 | 75 | 150 |
| GA030-S06 | 6 | 6650 | 75 | 150 |
| GA030-S07 | 7 | 5700 | 80 | 150 |
| GA030-S08 | 8 | 5000 | 80 | 150 |
| GA030-S09 | 9 | 4400 | 82 | 150 |
| GA030-S10 | 10 | 4000 | 82 | 150 |
| GA030-S12 | 12 | 3500 | 84 | 150 |
| GA030-S13 | 13 | 3200 | 84 | 150 |
| GA030-S14 | 14 | 3000 | 84 | 150 |
| GA030-S15 | 15 | 2800 | 85 | 150 |
| GA030-S16 | 16 | 2625 | 85 | 150 |
| GA030-S18 | 18 | 2300 | 85 | 150 |
| GA030-S24 | 24 | 1750 | 86 | 240 |
| GA030-S27 | 27 | 1550 | 86 | 240 |
| GA030-S36 | 36 | 1200 | 86 | 240 |
| GA030-S48 | 48 | 1000 | 88 | 240 |
| GA030-D05 | ±5 | ±4000 | 75 | 150 |
| GA030-D12 | ±12 | ±1750 | 80 | 150 |
| GA030-D15 | ±15 | ±1400 | 80 | 150 |
| GA030-D24 | ±24 | ±875 | 80 | 240 |
| GA030-D0305 | Vo1=+3.3, Vo2=+5 | Io1=5000, Io2=2000 | 72 | 150(Vo1) 240(Vo2) |
| GA030-D0512 | Vo1=+5, Vo2=+12 | Io1=5000, Io2=1250 | 75 | 150(Vo1) 240(Vo2) |
| GA030-D0515 | Vo1=+5, Vo2=+15 | Io1=5000, Io2=1000 | 75 | 150(Vo1) 240(Vo2) |
| GA030-D0524 | Vo1=+5, Vo2=+24 | Io1=5000, Io2=625 | 78 | 150(Vo1) 240(Vo2) |
